Sediment Treatment Systems - RDWS-NS Filter Series

RainDance Water Systems Well Water Sand, Sediment, Turbidity Filters Designed For

Whole House Water Filtration, Irrigation and Light Commercial Applications.

Find great well water filter Savings on all

RDWS-NS Sediment Sand filters from

RainDance Water Systems during our Well Water Treatment Event

RainDance Water Systems is dedicated to improving well water quality WITHOUT the need for using chemicals or salt. Thus no on going maintenance and no polluting chemicals being discharged.

SAND FILTERS: Customers experiencing high sediment, silt, sand, and turbidity please see our no-maintenance RDWS-NS sand sediment filtration systems. The RDWS-NS Series provide superior water filtration performance and solids loading capacity compared to conventional multi-media, water filtration media due to its unique structure, allowing particles (sediment) to penetrate deep into the filter bed to provide greater filtration at higher flow rates. The hardness, stability and high surface area of the filter granules makes it a perfect filtration media for virtually every application in the water treatment industry. High filtration performance water systems: 5 micron fine particle removal. High capacity filtration throughout the entire filter bed depth provides more than twice the capacity of multimedia filtration. High Service Flow at 3-4 times that of multimedia with superior filtration. Long lasting media (>5 years) not consumed in the process

Reverse Osmosis System Designs > Waters which are brackish and high in sodium and total dissolved solids (TDS) may require reverse osmosis water filtration. Our Reverse osmosis systems employ a semipermeable membrane that removes not only particles but also an extremely high percentage of dissolved contaminants-molecule by molecule- from raw tap water. For more information please see our Reverse Osmosis Resource Page.

Sand Filter Specifications

The RDWS-NS Series: Sand Sediment Filters. These maintenance-free systems are completely chemical and salt free. In other words they do not require salt pellets or chemicals for backwashing. Designed for whole house, irrigation, and commercial applications. Our NS Series provides filtration down to 5 microns. RainDance Water Systems RDWS Sand filters can be used on any domestic or industrial application where optimum sediment and turbidity removal is required.

RDWS- NS Series Standard Features:
RDWS-NS Series no routine filter cartridge maintenance!
RDWS-NS Series filter initiates an automatic backwash cycle during backwash, the direction of water flow is reversed, stirring up the filter bed, and loosening the trapped particles.
Drain water is reusable!
No chemicals need for regeneration !
No salt needed for backwashing!
No costly cartridges to change!
Filters sand down to 5 microns
Filters silt down to 5 microns
Filters sediment down to 5 microns
Long lasting media up to 5 years
Filter media does not add any harmful chemicals to the water
Filter Media is Certifed NSF /ANSI Standard 61
Simple to Install - connect inlet /outlet - drainline and plug in!
The RDWS-NS Series has a great warranty!
The RDWS-NS Series is considered a maintenance free sediment water filter. There are no routine filters to replace and requires no chemicals. The RDWS-NS Series will filter and clarify your water by filtering turbidity, sand, silt, sediment and suspended solids in the water. It will also improve the color of your water. The RDWS-NS series is controlled by a selfbackwashing control valve which will initiate a 20 minute backwash and then a 15 minute rinse (some applications require longer backwashes) approximately every 1-5 days depending on sediment levels. The filtration media will need to be exchanged approximately every 5 years*. This is easily accomplished with the use of a wet & dry vacuum which you use to vacuum out the old filtration media from the top of the filter. You then replace it with a new bed of filtration media which will last approximately another 5 years*. This is the only maintenance that the system will require. * Some applications may require a more frequent replacement interval.
RDWS-NS-125-10: Designed for a 10gpm flow rate
RDWS-NS-125-12: Designed for a 15gpm flow rate
Larger commercial flow rates can be found below.

Sediment Sand Filter

RainDance Water Systems RDWS-NS Series applications include sediment, sand, silt and turbidity filtration for residential well water owners, sea, pond, river, ground water, whole house and commercial well water sources. These systems also provide great pretreatment for sea water desalination systems and commercial reverse osmosis water purifiers.

Note: If you do not have the available flow rate for backwashing you may require (2) smaller systems plumbed in parallel to accommodate your higher flow rate and backwash capabilities.

Applications Include: Irrigation, Schools, Homes, Whole House Filtration, Commercial Water Treatment, RO Pretreatment, and more.

RainDance Water Systems RDWS-NS Non-Electric Sand, Sediment, Turbidity Backwashing Filter

NEW: Off-Grid  No Power Manual Backwashing RDWS-NS-9

The RDWS-NS-9 requires no electricity - designed to filter silt, sediment, sand, turbidity, and suspended solids from water supplies. Perfect for small homes, cabins, vacation homes, cottages, off-grid water applications or where power requirements and power outages are a concern. Request a Rebate.

Sediment Sand Filter



































Sediment Sand Filter

 Model #

 RDWS-NS-9 Non-Electric
Sediment Sand Filter

 System Function

 High Performance Sediment, Sand, Turbidity Filter

 Dimensions

 9" dia. X 56" ht.

 Non-Electric  Requires No Electricity

 Max. Flow Rate (gpm)

 6

Backwash Flow Rate (gpm)

 5

 Maximum Removal Capacities

5 Micron Sediment, Sand, Turbidity

 Max Pressure

 100psi/Min 30psi

 Required Maintenance

 Manual non-electric control valve is easy to operate; just move lever to move to a backwash and then rinse position - then back to the service position.

 System Weight

 120lbs

 Plumbing Size

 3/4" or 1"
Please Specify When Ordering

  Bypass Valve

 Yes, Included

  Tank Jacket

 Yes, Included

 Installation Instructions

 Yes, Included

  Tech Support

 Yes, Included

The RDWS-NS Series does not use salts or discharge salts when backwashing. Perfect for those on septic systems, irrigation, or whole house filter applications.

The Non-Electric-RDWS-NS-9 system is fully delivered with filtration media already in the tanks. New: User friendly - No special tools needed to attach control valve to tank - simply screw control valve on tank when ready for installation. This saves time, money, and headaches for the self-installer, your local plumber, or dealer !


Order Online or Call Toll-Free 1-877-788-8387

Non-Electric-RDWS-NS-9 Price: $1,395.00

*Free Shipping Within The Continental U.S.

[Add to Cart] [View Cart]


Save More - Save Now !

Online Rebtes


RAINDANCE WATER SYSTEMS HIGH FLOW MODEL RDWS-NS-125-10

 RainDance Water Systems High Performance NS Filters are designed to remove silt, sediment, sand, turbidity, and suspended solids from water supplies. Applications include irrigation, homes, cabins, swimming pools, pretreatment, and commercial water systems. Request a Rebate.

Sediment Sand Filter

































Sediment Sand Filter

 Model #

 RDWS-NS-125-10
High Flow
Sediment Sand Filter

 System Function

 High Performance Sediment, Sand, Turbidity Filter

 Dimensions

 10" dia. X 63" ht.

 Power  110v

 Max. Flow Rate (gpm)

 10

Backwash Flow Rate (gpm)

 7

 Maximum Removal Capacities

High Filtration Performance 5 Micron Sediment, Sand, Turbidity

 Max Pressure

 100psi/Min 40psi

 Required Maintenance

 No Routine Filters To Change  Automatically Self Backwashes

 System Weight

 150lbs

 Plumbing Size

 1" or 1.25"
Please Specify When Ordering

  Bypass Valve

 Yes, Included

  Tank Jacket

 Yes, Included

 Installation Instructions

 Yes, Included

  Tech Support

 Yes, Included

The RDWS-NS Series does not use salts or discharge salts when backwashing. Perfect for those on septic systems, irrigation, or whole house filter applications.

The RDWS-NS125-10 system is fully delivered with filtration media already in the tanks. New: User friendly - No special tools needed to attach control valve to tank - simply screw control valve on tank when ready for installation. This saves time, money, and headaches for the self-installer, your local plumber, or dealer !


Order Online or Call Toll-Free 1-877-788-8387

RDWS-NS-125-10 Price: $1,595.00

*Free Shipping Within The Continental U.S.

[Add to Cart] [View Cart]


Save More - Save Now !

Online Rebtes


RAINDANCE WATER SYSTEMS HIGH FLOW MODEL RDWS-NS-125-12

 RainDance Water Systems High Performance NS Filters are designed to remove silt, sediment, sand, turbidity, and suspended solids from water supplies. Applications include irrigation, homes, cabins, swimming pools, pretreatment, and commercial water systems. Request a Rebate.

Sediment Sand Filter

































Sediment Sand Filter

 Model #

 RDWS-NS-125-12
High Flow
Sediment Sand Filter

 System Function

 High Performance Sediment, Sand, Turbidity Filter

 Dimensions

 12" dia. X 62" ht.

 Power  110v

 Max. Flow Rate (gpm)

 High Flow 15gpm

Backwash Flow Rate (gpm)

 10

 Maximum Removal Capacities

High Filtration Performance 5 Micron Sediment, Sand, Turbidity

 Max Pressure

 100psi/Min 40psi

 Required Maintenance

 No Routine Filters To Change  Automatically Self Backwashes

 System Weight

 175lbs

 Plumbing Size

 1" or 1.25"
Please Specify When Ordering

  Bypass Valve

 Yes, Included

  Tank Jacket

 Yes, Included

 Installation Instructions

 Yes, Included

  Tech Support

 Yes, Included

The RDWS-NS Series does not use salts or discharge salts when backwashing. Perfect for those on septic systems, irrigation, or whole house filter applications.

The RDWS-NS125-12 system is fully delivered with filtration media already in the tanks. New: User friendly - No special tools needed to attach control valve to tank - simply screw control valve on tank when ready for installation. This saves time, money, and headaches for the self-installer, your local plumber, or dealer !


Order Online or Call Toll-Free 1-877-788-8387

RDWS-NS-125-12 Price: $1,795.00

*Free Shipping Within The Continental U.S.

[Add to Cart] [View Cart]


Save More - Save Now !

Online Rebtes

Note: If you do not have the available flow rate for backwashing you may require (2) smaller systems plumbed in parallel to accommodate higher flow rates and backwash capabilities.

Commercial & Industrial Well Water or City Water Sediment, Sand, Silt, Turbidity

SAND FILTERS: Customers experiencing high sediment, silt, sand, and turbidity please see our no-maintenance RDWS-NS sand sediment filtration systems. Superior media filtration technology. Based on a rare natural mineral that is highly processed and refined, It's unique properties allow it to radically alter the performance and cost of media filtration. The hardness, stability and micro-porous character makes it a perfect filtration media for virtually every application in the water treatment industry. Request our RDWS-NS Sand Filter Catalog and Price Guide via e-mail

Features
High filtration performance 5 micron removal.

High capacity filtration throughout the entire media bed depth provides more than twice the capacity of multimedia filtration.
High Service Flow 3-4 times that of multimedia with superior filtration.
Long lasting media (>5 years) not consumed in the process.
Simple NO ROUTINE FILTER REPLACEMENT MAINTENANCE, NON-Chemical periodic backwash keeps the media clean and operating efficiently.


Applications

Whole house well water filtration

RO Pretreatment superior SDI reduction
Cooling Towers unequalled Turbidity removal
Municipal Water Treatment, pressure and gravity filters higher flow, lower pressure drop and superior filtration performance
Wastewater Polishing exceptional TSS removal
Precipitated metals removal
Carwash reclaim and recycling
Irrigation

RDWS-NS Filter SERIES

RDWS-NS Sand Filter Water Filter Quote

(2 or more) RDWS-NS systems can be plumbed in parallel to accommodate larger flow rate capacities

 Part #

 Media Cubic ft.

 Tank Size

 Pipe Size

 Approx.

Weight LBS

 Service/Peak Flow Rate GPM

Price

Shipping quoted upon request

NS-18

 6.0

 18 x 65

 1.5"

 750

 22/33gpm

$2,677.00

NS-21

 7.0

 21 x 62

 1.5"

900

 30/50gpm

$2,875.00

NS-24

 10.0

 24 x 72

 2"

 1325

 35/62gpm

 $3,560.00

NS-30

 15.0

 30 x 72

 2"

 2075

 59/98gpm

 $4,934.00

NS-36

 20.0

 36 x 72

 2"

2700

 85/140gpm

 $5,639.00

Above RDWS-NS filter systems include tank, timer valve, distributor and media support gravel.
High Performance Silt, Sediment, Sand and Turbidity Removal System 5 Micron Filtration (Nominal)
Due to weight and ease of maneuverability - Tank and media are shipped separately on pallet.
Each commercial filter includes simple easy to follow step by step filling instructions.
To order call toll free 1-877-788-8387 Prices include filter media - Shipping quoted upon request
